Oil Transformer High Permeability Full Sealed
Oil Transformer High Permeability Full Sealed
Oil Transformer High Permeability Full Sealed
Oil Transformer High Permeability Full Sealed
Oil Transformer High Permeability Full Sealed
1 / 5
Oil Transformer High Permeability Full Sealed
Oil Transformer High Permeability Full Sealed
Oil Transformer High Permeability Full Sealed
Oil Transformer High Permeability Full Sealed
Oil Transformer High Permeability Full Sealed

Oil Transformer High Permeability Full Sealed

Still deciding? Get samples of $ !
Order Sample
Send Inquiry

Product Description

Basic Information

Model NO.
Oil Transformer
Core
Core-type Transformer
Cooling Method
Oil-immersed Type Transformer
Winding Type
Two-winding Transformer
Certification
ISO9001, CCC, CE
Usage
Power Transformer, Distribution Transformer
Frequency
Power Frequency
Shape of Core
Ring
Origin
China
HS Code
8504210000
Capacity
200 Piece
Package Size
100.00cm * 100.00cm * 100.00cm
Gross Weight
100.000kg

Product Description

Oil immersed series transformer:

S11-M series fully sealed oil immersed power transformer developed and produced has the advantages of low loss, low noise and high efficiency, which can achieve good energy-saving effect and reduce pollution. Compared with the ordinary oil immersed transformer, the fully sealed transformer cancels the oil conservator, and the change of oil volume is automatically adjusted and compensated by the elasticity of the corrugated sheet of the corrugated oil tank. The transformer is isolated from the air, so as to prevent and slow down the deterioration of oil and insulation aging, enhance the operation reliability, and avoid maintenance in normal operation.

Power Capacity: 25-2500KVA
Voltage Level: 10KV to 36KV and Others
Regulation: Off-circuit or On-load
Frequency: 50Hz or 60Hz

Operating Conditions: Altitude not exceeding 1000m, ambient temperature not exceeding 40°C. Connection symbols available as Dyn11, Yyn0 or as requested.

Oil Transformer High Permeability Full Sealed
Oil Transformer High Permeability Full Sealed
Oil Transformer High Permeability Full Sealed

Frequently Asked Questions

What are the main advantages of fully sealed oil-immersed transformers?
They offer low loss, low noise, and high efficiency. The fully sealed design prevents oil oxidation and insulation aging by isolating the oil from air, significantly increasing reliability.
How does the transformer handle oil volume changes?
The change in oil volume is automatically adjusted and compensated by the elasticity of the corrugated sheets in the corrugated oil tank, eliminating the need for an oil conservator.
Does this transformer require regular maintenance?
Due to the fully sealed structure, the transformer is isolated from the atmosphere, which avoids moisture entry and oil deterioration, making it virtually maintenance-free during normal operation.
Can the voltage and capacity be customized?
Yes, we support a wide range of power capacities from 25KVA to 2500KVA and various voltage levels (10KV to 36KV) to meet specific customer requirements.
What are the environmental limits for standard operation?
Standard units are designed for altitudes below 1000m and ambient temperatures up to 40°C. For conditions exceeding these limits, technical parameters can be modulated accordingly.
